(EDGE Driver-Mc): Zigbee Drivers for Motion, Open/Close, Moisture, Smoke-Co Sensors and others Devices

Hello Mariano,

I have a Konke Button

  • application: 28
  • endpointId: 01
  • manufacturer: Konke
  • model: 3AFE280100510001
  • zigbeeNodeType: SLEEPY_END_DEVICE

Raw Description:

  • 01 0104 0002 00 05 0000 0001 0003 0006 FCC0 02 0003 FCC0

it works fine with the device handler of a xiaomi button

Is it possible to add to any of yours driver?

1 Like

Sorry, I only have a driver for the smartthings button and this device does not fit in this driver.
There are other drivers for xioami buttons in the community, which might fit

1 Like

Hi is there a way for this hum/temp sensor?

  • application: 43
  • endpointId: 01
  • firmwareFullVersion: 00000043
  • firmwareImageType: 54179
  • firmwareManufacturerCode: 4417
  • manufacturer: _TZE200_locansqn
  • model: TS0601
  • zigbeeNodeType: SLEEPY_END_DEVICE
    Raw Description 01 0104 0051 01 04 0004 0005 EF00 0000 02 0019 000A
1 Like

Sorry, This device uses the exclusive cluster, Tuya EF00.
I don’t have any driver that works with that cluster

you can ask in another thread about edge drivers

1 Like

Are you able to add this device?
CentraLite motion sensor 3328-G
Motion-temperature-battery

Data
endpointId: 01
firmwareFullVersion: 18005310
firmwareImageType: 37
firmwareManufacturerCode: 4174
manufacturer: CentraLite
model: 3328-G
zigbeeNodeType: SLEEPY_END_DEVICE

1 Like

This device is in the process of being accepted for the new version of the stock driver.
If you want to wait for it to be published or do you want me to add it to mine?

  - id: CentraLite/3328-G
    deviceLabel: Centralite Motion Sensor
    manufacturer: CentraLite
    model: 3328-G
    deviceProfileName: motion-temp-battery
1 Like

Either is fine with me. I’m in no hurry. Thank you for all the work you’ve done!

1 Like

Added to this driver date version

β”Œβ”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”¬β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”
β”‚ Name        β”‚ Zigbee Motion Sensor Mc              β”‚
β”‚ Version     β”‚ 2022-03-15T19:41:40.729077           β”‚
β””β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”΄β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”˜
2 Likes

Hi Mariano.
You could update the β€œzigbee-multi-switch-Zemismart” driver source in Repositories on GitHub.

Good morning, could you adapt a driver for my Tuya presence sensor?

Thanks

Hi Giacomo,
I have updated the github repository of these drivers, but I am not going to update it anymore since it is not necessary, the Zigbee Multi Switch Mc should work fine for all the devices that used the Zigbee Multi Switch Zemismart Mc

1 Like

Added to this driver date version

β”Œβ”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”¬β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”
β”‚ Name        β”‚ Zigbee Motion Sensor Mc              β”‚
β”‚ Version     β”‚ 2022-03-16T19:21:27.455542           β”‚
β””β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”΄β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”˜
  - id: "_TYZB01_jytabjkb/Motion"
    deviceLabel: TS0202 Motion Sensor
    manufacturer: _TYZB01_jytabjkb
    model: TS0202
    deviceProfileName: motion-battery

Hey Mariano, gΒ΄day!

Another device for Zigbee Valve MC with some details. MOES SMART VALVE CONTROL.


Data

  • application: 50
  • endpointId: 01
  • manufacturer: _TZ3000_iedbgyxt
  • model: TS0001
  • zigbeeNodeType: ROUTER

Raw Description
01 0104 0100 01 07 0003 0004 0005 0006 E000 E001 0000 02 0019 000A

The curious is. That FP is based on thing edition to ZIGBEE VALVE stock device handler, but in this case Amazon Alexa will NOT get as new device, so… does not exist at the platform.
Then i tried changing to average ZIGBEE SWITCH DH and… Bingo! Alexa ready!

Do you think adding the fingerprint to your Zigbee Valve MC will allow alexa to find it? if not, whatΒ΄s the best solution? Add to any average switch like that or find the β€œalexa issue” on Valve driver?

Thank you as ever!

Added to this driver version

  - id: "Valve/TS0001"
    deviceLabel: Water Valve
    manufacturer: _TZ3000_iedbgyxt
    model: TS0001
    deviceProfileName: water-valve
β”Œβ”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”¬β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”
β”‚ Name        β”‚ Zigbee Valve Mc                      β”‚
β”‚ Version     β”‚ 2022-03-16T21:54:51.044256           β”‚
β””β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”΄β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”˜

I do not know.

If not works could try adding it to the zigbee switch driver

Firstly I would like to send a big thank you to @Mariano_Colmenarejo!
I have a Lidl Silvercrest 3-gang power strip and your edge driver works like a charm. It’s so great to have people like you here providing all of us with drivers for free.
I have two minor things to ask for, maybe it’s possible to support this:
Firstly, with the old DTH I used formerly I saw the three outlets as separate devices. I found I can change the setting to show all three plugs in the SmartThings app, but sadly only the β€œmain plug” is showing up in Alexa devices. I have some Echo routines where it would be great to also again make use of the 2nd and 3rd outlet.
Secondly, would it be possible to let the user customize the name of the three outlets? With the old groovy DTH I could name each β€œdevice”, which would of course be great if that would also work with the new edge driver.
Again, thanks a lot for your work and cheers from Germany,
Christoph

Hi @Chris74,

These are two requests that have been made to smartthings by various users.
Hopefully they can give us a solution.

Currently the only thing that can be done is to use 2 virtual switches and with automations to synchronize the state and actions of switch2 and switch3 with the virtual devices.

Also to facilitate the control of the three switches without opening it, you can choose in preferences a multiple mosaic with the 3 switches and the all switches

1 Like

Thanks a lot for clearing things up for me. So we have to hope the SmartThings team will adress this in the future. In the meantime the work-around with virtual devices will be sufficient for me for scenarios where local execution is not the goal anyway (ie Echo routines).
Best regards!

You can use virtual devices created with edge drivers that works locally.
You can install from this channel of @TAustin

1 Like

Could you add this Ikea light to your driver. Many of the Ikea lights are in stock driver but this one seems to be missing

  • application: 20
  • endpointId: 01
  • firmwareFullVersion: 23050631
  • firmwareImageType: 16643
  • firmwareManufacturerCode: 4476
  • manufacturer: IKEA of Sweden
  • model: TRADFRI bulb GU10 WW 400lm
  • zigbeeNodeType: ROUTER

This one seems to be new as well.

zigbeeNodeType: ROUTER
firmwareManufacturerCode: 4476
firmwareFullVersion: 10021655
application: 50
endpointId: 01
firmwareImageType: 10242
manufacturer: IKEA of Sweden
model: TRADFRI bulb GU10 CWS 380lm
