tomsyco · November 2, 2018, 9:14pm

A few weeks ago all of a sudden, a bunch of my Xiaomi Aqara devices dropped off the network. I cannot get them to reconnect. Anyone else having this issue. Do I need to remove them from the hub? I would like to avoid that.

idioffo89 · November 2, 2018, 9:51pm

I have been having the same issue for the past two weeks or more with some of my xiaomi devices. I can’t get them to stay connected for more than couple hours anymore and nothing changed in my setup so I’m thinking it has to do with the latest hub firmware update st pushed

mikejclark · November 4, 2018, 2:16pm

Have just added this DTH and changed my button to use it. Pulled this from the log:

14:05:00: info Button 3 was released
14:04:59: info Button 3 was held (Button 1 held)
14:04:55: info Button 3 was double-clicked (Button 2 pushed)
14:04:48: info Button 3 was single-clicked (Button 1 pushed)

I’m about to try a few things in webcore.
Anything in particular you want testing?

mikejclark · November 4, 2018, 2:52pm

How do I use the custom events? I can only see pushed or held in webcore.

I have two of these. Since changing to the new DTH is see this in the events.

2018-11-04 2:59:08.823 PM GMT
moments ago DEVICE button held Lounge Wireless was held
2018-11-04 2:58:26.405 PM GMT
moments ago DEVICE button pushed Lounge Wireless was double-clicked
2018-11-04 2:58:19.849 PM GMT
moments ago DEVICE button pushed Lounge Wireless was single-clicked
2018-11-04 2:58:12.791 PM GMT
moments ago DEVICE numberOfButtons 3 Lounge Wireless number of buttons is 3

Behold81 · November 4, 2018, 10:07pm

Thanks for that

Behold81 · November 4, 2018, 10:08pm

Thanks for that.

Interesting read. Shame they can’t choose how the data is processed based on a profile of the device.

veeceeoh · November 5, 2018, 8:59pm

[BETA] Xiaomi Aqara Button SmartThings DTH v1.3.1b

With @mikejclark reporting back on his 1-button Aqara Wireless Smart Wall Switch (model WXKG03LM), it appears that there are actually two revisions of this product: One which only sends a “button pushed” message, and the other which has single-click, double-click, and held functionality. From his report, it appears my update to the Aqara button DTH is working as expected, but I’ve added comments regarding the different revision models.

Also, I decided to add lastHeld and lastHeldCoRE custom attributes for events that can be used with WebCoRE.

The updated DTH code can be copied directly from here.

Changes

added custom attributes lastHeld (with human-readable date/time stamp) and lastHeldCoRE (with UNIX Epoch date/time stamp) which can be utilized in WebCoRE
added comments in header section related to original/new revisions of 1-button Aqara Wireless Smart Wall Switch model WXKG03LM, and the 2-button WXKG02LM
added comments specific to new revision of WXKG03LM in button press parsing function
other minor fixes

Thanks for reporting back on what you’re seeing with your model WXKG03LM. So it appears there are two revisions of this model!

In your WebCoRE screenshot it looks like you are using button events to compare values to. The custom events are based on custom attributes, not on button events.

Look for these: lastHeldCoRE, lastPressedCoRE, and lastReleasedCoRE. When the events on these custom attributes happen, they are set to not display in the events list, because it would just clutter the events list display in the SmartThings (Classic) Mobile App. You can confirm they are happening by turning on debug message logging in the preference settings for the button in the Mobile App.

It would be super helpful to make sure your model WXKG03LM button doesn’t send any message when you release the button after holding it (which some of the other Aqara buttons do). The way to check this is turn on debug message logging and then look for a message after the “Lounge Wireless was held” message which includes “Parsing” but without being followed by “Creating event”.

The other thing I’m curious about is whether the two different models of the WXKG03LM button report the same ZigBee model information. This can be found in the “Data” section of the Device page for your button in the IDE (My Devices tab → click on the name of your button), like this:

mikejclark · November 7, 2018, 10:37pm

Thanks for explaining, I’ll give this a go.

Not really sure what this means. Do I need to enable the logging first?
I held the button first, followed by a single push a short time after. Does this help?

Looks like I have two versions of this switch. The first shown here is for the logs above.

Automated_House · November 12, 2018, 10:59pm

It looks like the latest contact, switch, water and button from Lumi (manufacturer of Xiaomi Mi and Aqara) are zigbee 3.0 certified. Which means in theory they will work with standard zigbee communication

veeceeoh · November 14, 2018, 12:32am

In theory!

However, looking through the certification documentation for just the new Door & Window Sensor, this appears to be the good news we’d want to see from Xiaomi moving forward:

So from what I understand, this and the other new ZigBee 3.0 certified Aqara devices will attempt to rejoin a mesh network that it was previously on, which is something all previous Xiaomi devices fail to do. Even after searching through some of the ZigBee Alliance’s certification documentation, I’m not sure what the “ZLT3” designation refers to, but the “M” means “Mandatory”, and “Yes” of course means that function is supported. My hope is that the new Aqara devices will also automatically rejoin the network of a ZigBee 2.1 hub.

Interestingly this certification process has been going on since 2015, and thankfully all of the ZigBee 3.0 certified Aqara devices have new model numbers, and the new product names listed on the ZigBee Certification website end with “T1”, except for the “Wall Switch (with Neutral, Double Rocker) S2”. I say “thankfully”, because recently Xiaomi has released new revisions of some of their Aqara ZigBee products under existing model numbers, but with different hardware feature sets.

Because Xiaomi’s website hasn’t been updated to display the new “T1” & “S2” product lineups, and there are multiple older models with the same external case but different features, I expect things to be a confusing mess for people looking to buy Xiaomi devices. It’s also a complete mess in terms of supporting all of the models / variants in SmartThings device handlers. With that in mind, I am building a spreadsheet to make sense of all of the different models / revisions of Xiaomi’s ZigBee smart home devices.

Here’s a preview:

Xiaomi Device Name	Device Type	Model / SKU	Zigbee Model	Certification
Aqara Cube Controller	Multi-function Controller	MFKZQ01LM	lumi.sensor_cube
Original Door and Window Sensor	Magnetic Contact Sensor	MCCGQ01LM	lumi.sensor_magnet
Aqara Door and Window Sensor	Magnetic Contact Sensor	MCCGQ11LM	lumi.sensor_magnet.aq2
Aqara Door and Window Sensor T1	Magnetic Contact Sensor	MCCGQ12LM		ZigBee 3.0
Original Motion Sensor	IR Motion Sensor	RTCGQ01LM	lumi.sensor_motion
Aqara Motion Sensor	IR Motion Sensor	RTCGQ11LM	lumi.sensor_motion.aq2
Aqara Smart Bulb	Smart Bulb (E27)	ZNLDP12LM
Original Smart Plug	Plug-in Outlet Switch	ZNCZ02LM	lumi.plug
Aqara Smart Plug	Plug-in Outlet Switch	ZNCZ12LM	lumi.ctrl_86plug.aq1
Original Temperature and Humidity Sensor	Temp & Humidity Sensor	RTCGQ01LM	lumi.sensor_ht
Aqara Temperature and Humidity Sensor	Temp & Humidity Sensor	WSDCGQ11LM	lumi.weather
Aqara Wall Outlet	In-wall Outlet Switch	QBCZ11LM
Aqara Wall Switch - Single (no Neutral)	Wall Switch (no neutral)	QBKG04LM	lumi.ctrl_neutral1
Aqara Wall Switch - Double (no Neutral)	Wall Switch (no neutral)	QBKG03LM	lumi.ctrl_neutral2
Aqara Wall Switch - Single (w/Neutral)	Wall Switch w/Neutral	QBKG11LM	lumi.ctrl_ln1.aq1
Aqara Wall Switch - Double (w/Neutral)	Wall Switch w/Neutral	QBKG12LM	lumi.ctrl_ln2.aq1
Aqara Wall Switch S2 - Double (w/Neutral)	Wall Switch w/Neutral	QBKG20LM		ZigBee 3.0
Aqara Water Leak Sensor	Water Contact Sensor	SJCGQ11LM	lumi.sensor_wleak.aq1
Aqara Water Leak Sensor T1	Water Contact Sensor	SJCGQ12LM		ZigBee 3.0
Original Smart Wireless Switch	Multi-function Button	WXKG01LM	lumi.sensor_switch
Aqara Wireless Mini Switch	Multi-function Button	WXKG11LM (2015)	lumi.sensor_switch.aq2
Aqara Wireless Mini Switch	Multi-function Button	WXKG11LM (2018)	lumi.remote.b1acn01
Aqara Wireless Mini Switch	Multi-function Button	WXKG12LM	lumi.sensor_switch.aq3
Aqara Wireless Mini Switch T1	Multi-function Button	WXKG13LM		ZigBee 3.0
Aqara Wireless Remote Switch - Single	Multi-function Button	WXKG03LM (2016)	lumi.sensor_86sw1 or lumi.sensor_86sw1lu
Aqara Wireless Remote Switch - Single	Multi-function Button	WXKG03LM (2018)	lumi.remote.b186acn01
Aqara Wireless Remote Switch - Double	Multi-function Button	WXKG02LM (2016)	lumi.sensor_86sw2 or lumi.sensor_86sw2Un
Aqara Wireless Remote Switch - Double	Multi-function Button	WXKG02LM (2018)	lumi.remote.b286acn01
Aqara Vibration Sensor	Accelerometer Sensor	DJT11LM	lumi.vibration.aq1
MiJia Honeywell Smoke Detector	Smoke Detector	JTYJ-GD-01LM/BW	lumi.sensor_smoke

veeceeoh · November 14, 2018, 1:02am

That screenshot was of the events and then WebCoRE-specific log output. What I’m hoping to see is the debug & info message output for just the button itself on the Live Logging page of your IDE. Log output for a specific device or SmartApp can be isolated by clicking on the URL link of its name at the top of the Live Logging page - so in this case, clicking on the name “Lounge Wireless” (if that’s the new revision lumi.remote.b186acn01 switch).

To turn on debug message logging, it needs to be turned on in the preference settings for that device, in the SmartThings “Classic” mobile app, as seen here:

I’d only need to see the log output for your lumi.remote.b186acn01 version of the WXKG03LM switch. This is the new revision that I wrote a post about back in October.

I am sorry to say that the “original” lumi.sensor_86sw1 version of the WXKG03LM switch definitely only supports single press in hardware, and not double-press or hold. Also note that if you hold the button of the lumi.sensor_86sw1 version for 5 or more seconds, it will go into pairing mode.

From your screenshots and further testing, I see that the new beta Aqara Button DTH needs some fixes and edits. I should hopefully be posting with a new beta version to try soon.

Thanks for all your help!!

Behold81 · November 15, 2018, 10:24am

I take it the double switch will not work still though as a double…?

veeceeoh · November 15, 2018, 4:40pm

I don’t yet have any information about how the new lumi.remote.b286acn01 version of the WXKG2LM Aqara Wireless Smart Wall Switch switch sends Zigbee messages. And there’s no information about the new QBKG20LM Aqara Wall Switch S2 either.

So the answer is: I have no idea.

Paralytic · November 15, 2018, 6:23pm

Thanks for your continued work on this. One small note, all my original Temp and Humidity sensor have a different model - from the IDE devices page:

application: 02
endpointId: 01
manufacturer: LUMI
model: lumi.sens

veeceeoh · November 15, 2018, 11:36pm

Thanks for the report, but that’s not a different model.

The full ZigBee model text just gets truncated for some reason during the pairing process if the reset button is pushed repeatedly (which is what SmartThings users need to do to complete the pairing). This behavior has been mentioned in a forum thread for another HA solution here.

hoveeman · November 17, 2018, 4:23pm

I can not get these guys to stay connected for more than an hour or two. I followed the pairing instructions and made sure to see the collectall and zbjoin message for each device when pairing. I’ve tried resetting and repairing multiple times. My device breakdown is the following:

5x Aqara Leak Sensors
3x Aqara Motion Sensors
3x Aqara Temperature Sensors
6x Aqara Door Sensors
My hub is the Samsung SmartThings dongle for my Nvidia Shield… Not sure if that is the difference maker?

I tried adding a Zigbee repeater to the mix after I paired everything to see if that would help. It did not.

Every device shows a Zigbee ID and Device Network ID on the developer portal.

Any tips or things to look for? Appreciate it!

veeceeoh · November 17, 2018, 6:51pm

Yes it is.

Before I bought a SmartThings v2 hub, I was using the SmartThings Link for NVIDIA Shield TV. My Xiaomi devices NEVER stayed connected to it for more than an hour or two.

The reason for this is quite well documented. ZigBee hubs and repeaters (routers) will drop the connection of ZigBee end devices that don’t check in often enough based on what’s called End Device Aging Timeout. However, ZigBee end devices whose connection have been dropped but attempt to check in can still rejoin the network after receiving a rejoin request from the hub / repeater.

Unfortunately, Xiaomi devices do not follow ZigBee protocol of rejoining the network when requested.

The only way to get around this issue is to use a hub / repeaters which have an End Device Aging Timeout period that is longer than the normal check in frequency of Xiaomi devices (50 or 60 seconds depending on the model.)

The End Device Aging Timeout period length is not user-adjustable (with the exception of XBee devices) and is not normally part of any published ZigBee information for hubs / routers. So compatibility with Xiaomi devices can only be discovered through trial and error.

Based on my experience and reports by various users, the SmartThings Link for NVIDIA Shield presumably has an End Device Aging Timeout period shorter than the check in frequency of Xiaomi devices, while the v2 hub does not. Also a seeming majority of ZigBee repeater-capable devices are incompatible with Xiaomi devices because of the End Device Aging Timeout period / no network rejoin issue.

Good sources of information:

[OBSOLETE] Xiaomi Sensors and Button (beta) Community Created Device Types

Although they aren’t officially supported I know a lot of people use these sensors so I’ve been looking into the issue with the 0.18.X firmware on my own time and I think I may know what’s going on. As you probably know, the Xiaomi sensors are very sleepy. Most sleepy end devices that we support will wake up every 6 seconds to 2 minutes to check for messages and to make sure its parent knows it is still there. The Xiaomi sensors do this closer to once an hour. That is zigbee compliant behavior so everything is fine so far. The zigbee specification includes a section called End Device Aging. It states that a parent must forget about a child that doesn’t check in for a certain amount of time. In other words if the parent (like the hub or another router on the network) hasn’t heard from a d…

Zigbee - from flakey to stable Devices & Integrations

I have been suffering from losing devices on an off, general instability… having only about 3 days of uptime before something stopped working. It annoyed me not knowing why… so i started to keep track of variables that were triggering it. The only thing i could pinpoint was if lots of people were in the house (with mobile phones), then bad stuff would happen. So, lets get more scientific. I bought an £11 xbee (actually £11 for 2)) a £3 usb converter and booted up XCTU, sketched together some settings from lots of other posts on xbee and connected it as a thing. I can now see my zigbee mesh… i can start to play. first thing i saw is lots of mobile devices = lots of intereference. What i saw was a marginal mesh at best, very weak signal between the hub, and the outlet, and pathetic signa…

[OBSOLETE] Original & Aqara Xiaomi Zigbee Sensors (contact, temp, motion, button, outlet, leak, etc) Community Created Device Types

I have been monitoring a few of these threads for a while now hoping someone will have a solution would find a solution to the disconnecting sensor problem. As far as I can tell, a method still has not been found. I have three xiaomi aqara window/door sensors (the squarish ones with the button). I can get them all to connect but they consistently disconnect after a hour or two. The only other devices I have on my hub are a number sengled element bulbs and four hue white bulbs that are direct connected to the hub as well. As far as I am aware, none of those act as repeaters so my aquara sensors should be direct connecting to the hub. The only twist I can think of to my setup is that I use the SmartThings Link as my hub (which is the dongle that plugs into an Nvidia Shield TV). I have had …

hoveeman · November 17, 2018, 7:05pm

Thank you very much for that detailed response. I may go pick up a v2 hub and give it a try. Appreciate it!

AnubizDK · November 18, 2018, 6:04pm

So i tested a bit further with the 1.3.1b…
I think there might be a small bug with this version and my WXKG03LM and a WXKG12LM i’ve tried it on.
When i tap the button in the (Classic) app for this device, it shows a Held instead of a Pushed in the app.
I still can’t get the HOLD to work with the physical button, but now the IDE log show this when i press the button in the app:

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.57.28: debug Aqara Switch WXKG03LM: Setting Last Held to current date/time

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.57.28: info Aqara Switch WXKG03LM was held (Button 1 held)

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.57.28: info Aqara Switch WXKG03LM: Virtual App Button Pressed

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.57.28: debug Aqara Switch WXKG03LM: Setting Last Held to current date/time

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.57.28: info Aqara Switch WXKG03LM was held (Button 1 held)

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.57.28: info Aqara Switch WXKG03LM: Virtual App Button Pressed

It stays in HELD mode in the app until i press the physical button, and then shows this:

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.59.08: debug Aqara Switch WXKG03LM: Creating event [name:button, value:pushed, data:[buttonNumber:1], descriptionText:Aqara Switch WXKG03LM was pushed, isStateChange:true]

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.59.08: debug Aqara Switch WXKG03LM: Setting Last Pressed to current date/time

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.59.08: info Aqara Switch WXKG03LM was pushed (Button 1 pushed)

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.59.08: debug Aqara Switch WXKG03LM: Setting Last Pressed to current date/time

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.59.08: debug Aqara Switch WXKG03LM: Parsing 'on/off: 1'

[4ce011fe-a84b-4d84-9ffa-cae07dbdce4d](https://graph-eu01-euwest1.api.smartthings.com/ide/logs#4ce011fe-a84b-4d84-9ffa-cae07dbdce4d) 18.59.08: debug Aqara Switch WXKG03LM: Parsing 'on/off: 1'

Thought that you maybe could use this info…

wasim · November 19, 2018, 6:52pm

Hi everyone I just want to confirm xiaomi device working with Samsung connect pro without any issue since they release new firmware which is 22.52 I’m using xiaomi device with new firmware where since 4 days without dropping any connection and without disconnecting working perfectly fine without any problems I have more than 30 device which is leaks sensors open and close sensor motion sensor humidity sensor and push buttons since 4 days they all working fine I’m so happy because I have Samsung home connect pro since long time and I was waiting for new update
